Technical details:
Rated current: 60A/80A/125A/150A/200A
Operation voltage: 1000V
Insulation resistance: > 2000MΩ (DC1000V)
Contact resistance: 0.5mΩ Max
Terminal temperature rise: <50K Withstand voltage: 3000V Mechanical life: no-load plug in/out >10000 times
Insertion force: <100N
Operating temperature: -30℃～﹢50℃
| Model | Rated Current | Cable Specification |
|---|---|---|
| VGS-EP03-60 | 60A | 2×5AWG+1×9AWG+6×18AWG |
| VGS-EP03-80 | 80A | 2×5AWG+1×9AWG+6×18AWG |
| VGS-EP03-125 | 125A | 2×2AWG+1×8AWG+6×18AWG |
| VGS-EP03-150 | 150A | 2×1AWG+1×8AWG+6×18AWG |
| VGS-EP03-200 | 200A | 2×2/0AWG+1×6AWG+6×18AWG |
