Technical details:
Rated current: 80A/150A/200A
Operation voltage: 1000V DC
Case Material: thermoplastic, flame retardant grade UL94 V-0
Contact bush: copper alloy,silver plating
Operating temperature: -30℃～﹢50℃
Insulation resistance: >2000MΩ(DC1000V)
Terminal temperature rise: <50K Contact resistance: 0.5mΩ Max Mechanical life: no-load plug in/out >10000 times
Withstand voltage: 3200V
