User Interface
Cable length:5m/7.5m/10m
Cable specification:
7kw 3x6mm²+2×0.5mm²
11kw/21kw 5×2.5mm²+2×0.5mm²/5x8mm²+2×0.5mm²
Enclosure material: Plastic PC
Start mode: Plug and Play/RFID card/APP for Optional
Safety
Application standard:GB/T18478
Mechanical life: Plug in/Pull out>10000Times
Ingress protection: IP65
Electrical Protection: Over Current, Over/Under Voltage, Over Temperature, Surge, Short-Circuit, Leakage, Ground
Environment
Installation: Wall Mounted/Pole Mounted
Working Temperature:-25°C~45°C
Working Humidity：5%~95%
Specification
| Model | VGS-AS03-GB-07 | VGS-AS03-GB-11 | VGS-AS03-GB-21 |
|---|---|---|---|
| Power Supply | 1 Phase | 3 Phase | 3 Phase |
| Rated Voltage | 220V | 400V | 400V |
| Max Current | 32A | 16A | 32A |
| Max Power | 7KW | 11KW | 21KW |
| Certification | CQC | CQC | CQC |
| Optional Communication | Wi-Fi/Bluetooth, RS485/CAN, OCPP | Wi-Fi/Bluetooth, RS485/CAN, OCPP |
